Features and Benefits:

• Fluids Handled: Antifreeze, Synthetic and Mineral Oils, Waste Oil Evacuation
• Markets Served: Fleet service, Lube Trucks, Mining equipment maintenance, General Manufacturing, Mass Transit Maintenance, Railroad
• Very tough construction large capacity reels, able to stand regular use and abuse in Intensive Duty applications.
• Fatigue resistant steel spring for years of durable performance and even load when pulling and recoiling the hose.
• Fully ported shaft and swivel.
• Spool mounted on two permanently lubricated and sealed ball bearings to reduce torque load on spring for smooth retraction and longer life.
• Large latching area for easier operation.
• Hose guide arm can be placed in different positions to accommodate any method of mounting.
• Narrow footprint allows mounting more reels on the same surface.
• Hose Length: 50', 75', 100'
• Hose ID: 1", 3/4", 1/2"
• Outlet Thread: 1" NPT(M), 3/4" NPT(M), 1/2" NPT(M)
• Max. Working Pressure: 1,250 psi, 2,000 psi
• Hose Length: 50', 75', 100'
• Hose ID: 1", 3/4", 1/2"
• Outlet Thread: 1" NPT(M), 3/4" NPT(M), 1/2" NPT(M)
• Max. Working Pressure: 1,250 psi, 2,000 psi



Full metal heavy duty double pedestal hose reels, can handle up to 50' x 1", 60' and 75' x 3/4" or 100' x 1/2" hose.
